| Model Name | DLF1015-I | DLH1015-I | |
| Description | 10.1" TFT LCD, 1000 nits LED backlight, 1280x800 | ||
| size | 10.1" | ||
| Display area (mm) | 216.9(H) x 135.6(V) | ||
| Brightness | 1000 cd/m² | ||
| Resolution | 1280x800 | ||
| Aspect ratio | 16:10 | ||
| Contrast ratio | 900:1 | ||
| Pixel pitch (mm) | 0.1695 (H) x 0.1695 (V) | ||
| Pixel per inch (PPI) | 149 | ||
| Viewing angle | 170° (H), 170° (V) | ||
| Color saturation (NTSC) | 53% | ||
| Display colors | 16.7M | ||
| Response time (Typical) | 25ms | ||
| Video interface | LVDS | VGA, DVI-D, HDMI | |
| Input power | DC 12V | ||
| Power consumption | 6W | 11W | |
| Dimensions (mm) | 229.5x151.1x4.23 | 229.5x151.1x4.23 | |
| Bezel size (U/B/L/R) | 6.27/6.73/4.47/5.57 | 6.27/6.73/4.47/5.57 | |
| Weight (Net) | 0.15 kg | ||
| OSD key | 4 keys (Power switch, menu, +, -) | ||
| OSD control | Brightness, color, contrast, H/V position… etc | ||
| Operating temperature | 0°C ~ +50°C | ||
| Storage temperature | -20°C ~ +60°C | ||
