Stretch Digital Display

4475-I

44.7” Resizing LCD, 1000nits LED Backlight, 2160 x 2160
  • Resizing LCD
  • 44.7” Square Display
  • Special Screen 1:1
  • High Brightness 1000 nits
  • Sunlight Readable
  • LED Backlight
  • Low Power Consumption
  • BL MTBF: 100,000 hours

主要特色

  • Sunlight Readable

  • Low Power Consumption

Model Name

SSD4475-I

SSF/SSH4475-I

Description

44.7” Resizing LCD, 1000nits LED Backlight, 2160 x 2160

Screen Size

44.7”

Display Area (mm)

803.52(H) x 803.52(V)

Brightness

1000 cd/m2

Resolution

2160 x 2160

Aspect Ratio

1:1

Contrast Ratio

6200 : 1

Pixel Pitch (mm)

0.372(H) x 0.372 (V)

Pixel Pre Inch (PPI)

68

Viewing Angle

178°(H),178°(V)

Color Saturation (NTSC)

83%

Display Colors

1.07G

Response Time (Typical)

9.5ms

Panel Interface

V-by-One

Input Interface

HDMI, DP

Input Power

DC24V

Power Consumption

137W(140W with AD Board)

OSD Key

5 Keys (Power Switch, Menu, +, -,Exit)

OSD Control

Brightness, Color, Contrast, Auto Turing, H/V Position…etc

Dimensions (mm)

831.8 x 831.8 x 75.4

829.2 x 829.2 x 27

Bezel Size(U/B/L/R)

14.14/14.14/14.14/14.14 mm

12.84/12.84/12.84/12.84 mm

Mounting

VESA 400x300,400x200

Weight (Net)

21Kg

12.1Kg

Operating Temperature

0 ˚C ~ 50 ˚C

Storage Temperature

-20 ˚C ~ 60 ˚C
