| Model Name | DLF5505-B | DLH5505-B | DLD5505-B |
| Description | 55” TFT LCD, LED Backlight 1200nits, UHD (3840x2160) | ||
| size | 55" | ||
| Display area (mm) | 1209.6(H) x 680.4(V) | ||
| Brightness | 1200 cd/m² | ||
| Resolution | 3840x2160 | ||
| Aspect ratio | 16:9 | ||
| Contrast ratio | 1200:1 | ||
| Pixel pitch (mm) | 0.315 (H) x 0.315 (V) | ||
| Pixel per inch (PPI) | 80 | ||
| Viewing angle | 178° (H), 178° (V) | ||
| Color saturation (NTSC) | 80% | ||
| Display colors | 1.07G | ||
| Response time (Typical) | 8ms | ||
| Video interface | V-by-One | VGA, DVI-D, HDMI, DP | |
| Input power | AC100~240V | ||
| Power consumption | 160W | 165W | 180W |
| Dimensions (mm) | 1240 x 711 x 21.5 | 1242.6 x 713.6 x 74.3 | |
| Bezel size (U/B/L/R) | 14/14/14/14 | 15.3/15.3/15.3/15.3 | |
| Weight (Net) | 25.5 kg | 37.5 kg | |
| Mounting | VESA 400x200, 400x300 | ||
| OSD key | 5 keys (Power switch, menu, +, -) | ||
| OSD control | Brightness, Color, Contrast, Auto Turing, H/V Position…etc | ||
| Operating temperature | 0°C ~ +50°C | ||
| Storage temperature | -20°C ~ +60°C | ||
| Product approval | CE, FCC | ||
下载
-
标题
DLF_H5505-B
类型Datasheet
发布日期2022/Mar/02
-
标题
DLD_5505-B
类型发布日期2022/Feb/25
