| Model name | DLS5502-B |
| Description | 55” TFT LCD, 350 nits, FHD(1920x1080) SDM Solutions |
| Size | 55” |
| Display Area (mm) | 1209.6(H) x 680.4(V) |
| Brightness | 350 cd/m² |
| Resolution | 1920x 1080 |
| Aspect Ratio | 16:9 |
| Contrast Ratio | 1600 : 1 |
| Pixel Pitch (mm) | 0.63(H) x 0.63(V) |
| Pixel Pre Inch (PPI) | 40 |
| Viewing Angle | 178°(H),178°(V) |
| Color Saturation (NTSC) | 95% |
| Display Colors | 16.7M |
| Response Time (Typical) | 8ms |
| Video interface | SDM-S/SDM-L interface |
| SDM Slot | SDM-S/SDM-L |
| Input Power | AC100~240V |
| Power Consumption | 108W (Panel Model Only) |
| Dimensions (mm) | 1233x709.4x71.6 |
| Bezel Size(U/B/L/R) | 10.2/16.8/10.7/10.7 mm |
| Weight (Net) | 28 kg |
| Mounting | VESA 400x 400 |
| OSD key | 5 Keys (Power Switch, Menu, +, Exit -) |
| OSD control | Brightness, Color, Contrast, Auto Turing, H/V Position…etc |
| Operating Temperature | 0 ˚C ~ 50 ˚C |
| Storage Temperature | -20 ˚C ~ 60 ˚C |
